13 Июл. 2015 г.Объектив goproDon't get the pliers too close to the circuit board to avoid accidentally unwiring something.Now put the front cover face down and push down on it, the lip facing down, until the lip pops out. Take off the front cover of the housing and heat it up close to the shaft around the lip to loosen the glue seal. If you did reapply the lip, use the included rubber grip sleeve, which will go down between the lens and the lip. To remove the lens, start by overtightening it - this will help to break the glue seal further - then go counter-clockwise to take it out. You can focus the lens by plugging it into your television using HDMI or AV composite video cables. Now take the new lens and apply the rubber band gasket (not all lenses come with this) - this creates a force that will hold your lens in place while threading and will not vibrate out of focus. First you need to activate the live video output function on the GoPro HD to a TV or monitor using the 2.5mm to 3 way red yellow and white cable (the yellow is for composite video) that came with your GoPro HD camera. Installation: Using the small Phillips screwdriver, remove the 7 screws located in the battery compartment, then 1 other screw located inside by the circuit board right next to the USB port. You can either keep the lip off or reapply it after reinstalling your new lens; keeping the lip off allows you to macro focus with your camera. Tip: It’s best to over tighten the lens a little first to help break the glue seal then twist counter-clockwise to unthread the seal. Disclaimer: Performing this lens change may damage your camera if you’re not extremely careful.  The HERO 2's shaft has on a lip on it as well - the threads don't start for about 4mm down and it could be cut off if that's what you'd like to do. Now put the screws back on the battery compartment, and your lens is installed and ready to use! When reassembling the camera, make sure the LCD read out is lined up with its respective square. After you remove the stock lens, carefully thread in the new lens evenly, as it should thread in very smooth with a little force needed, if you start to notice its off threading, or need to use maximum force to thread it in, then stop and twist it back out. Reverse thread the lens a little to make sure it locks down and assure it's going straight and even to avoid crossthreading. Assemble the GoPro HD back together and use the foam O-ring that we include (depending on lens selection) so that it fits around the lens to hide the circuit board. When reapplying screws for the inside of the camera, we recommend you put two of them and tighten them a little bit, and then do the same for the other two, and then go back and tighten them all completely and evenly. If you didn't put the lip back on the lens when reassembling the camera, use the included foam O-ring around the lens to protect the circuit board. Once you are threading it in evenly, then you can macro focus the lens by looking at the monitor with a battery inserted to power it on. Before you get started: When you are removing the original wide angle stock GoPro HD lens you will need to do this in a well lighted area to keep track of the 7 screws and 2 buttons that can easily get lost.  |
